Automotive Tire Manufacturing

Automotive Tire Manufacturing

Spring-applied, secure holding BF2400 One-Way Clutch/Tension Brake Model BF2400 is a specially designed one-way clutch and mechanical tension brake assembly that is made for the loader system of a tire press. The Carlson Company manufactures the sprocket using a one-way clutch, shaft, brake, and mounting pedestal. The tension brake is spring applied and always engaged, […]

Bakery Lines

Bakery Lines

Precision stopping and starting in milliseconds UBSPC5 Clutch Carlson’s Model UBSPC5 is a totally enclosed, single position air applied clutch that becomes a torque limiter when an overload condition exists on the driven side of the clutch. The UBSPC5 has a torque rating of 650 in/lbs @ 80 PSI. When air enters the bearing mounted, […]

Conveyor Systems

Conveyor Systems

For more precise, error-free package routing TSC150XDN Conveyor Clutch The Carlson TSC150XDN Conveyor Clutch is a modification of the standard TSC150IM model. It includes a 1.000″ bore (oversized from the standard unit) and a backplate configuration that has a 5.5″ pitch diameter, 1 groove, B section integral sheave. The clutch engages an air applied diverter […]

Textile Industry

Textile Industry

Tension hold for exacting textile processing CB1000(A) Tension Brake Model CB1000(A) Tension Brake is a brake specifically designed to be placed on textile machinery and hold tension on the cloth web as it is being processed. The design of the brake dictates that it must have a heat dissipation capacity of .8 HP at 200 […]

Metal Converting

Metal Converting

Driveline protection for sheet metal levelers Model BC Friction Torque Limiter Model BC Friction Torque Limiters have been used in the metal converting industry, primarily on “sheet metal levelers”. Variations of the spring applied, single or multiple friction lining torque limiters have been used or quoted in many other industries. The simple mechanical design uses […]

Meet Packing And Processing

Meat Packing & Processing

Total enclosure ensures no grease contamination MDC550X11 Hydraulic Clutch The MDC550X11 hydraulic clutch is used in the meat packing/meat processing industry as a clutch that engages and disengages a meat pump. The clutch is hydraulically actuated and has a torque rating of 455 ft lbs @ 150 PSI. Construction of the clutch includes multiple, dry […]

Off Shore Oil Production

Off Shore Oil Production

Static holding brakes on platform winch systems Model HPB Spring Applied/Air Release Oil Filled Brake Model HPB Spring Applied/Air Released Brakes are designed to mount on the rear C-flange of motors, or between the flanges of motors and reducers or pumps. The brakes contain multiple friction linings that are immersed in an oil bath, providing […]
